Which way to blow my ceiling fan in a split level house

2 years ago

I know that that rule of thumb for a ceiling fan is counterclockwise in the summer, clockwise in the winter. But this is an odd situation.

I'm in a split level home, roughly 700 sq.ft per level. The heat pump is in the basement, which is the coolest part of the house. But I've converted 2 of the 3 upstairs bedrooms to home offices, and that tends to be the hottest part of the house! But we spend 8-12 hours in these offices, then 8-9 hours in the upstairs bedroom.

In my upstairs office and the bedroom, I have the ceiling fans blowing counterclockwise. But my girlfriend's office doesn't have a ceiling fan, the attic access is in the way so she doesn't have anything but a single vent :-(

How should I set the ceiling fan in the living room to make the upstairs cooler? Am I right in thinking that, if I blow the living room ceiling fan counterclockwise, then it would suck cold air from the upstairs and make them hotter?

Here's the living room from the upstairs. The ceiling fan is roughly even with the top of the banister. And please ignore the towel and gate, I'm dealing with an elderly dog :-(

Sort by:Oldest

Comments (3)

HU-867564120
2 years ago
I think it is unrealistic to expect that a ceiling fan in one room will help your cooling issues in the rest of the house.

Some thoughts:

- Close down the lower level registers.

- Increase the blower speed.

- Increase the attic insulation.

- Install sun blinds.

- Move the attic access so your girlfriend can have a ceiling fan.

- Lower the thermostat setting.

- Switch offices so you swelter and your girlfriend has a ceiling fan.
Jason, zone 7A, near Greensboro NC
Original Author
2 years ago
I think it is unrealistic to expect that a ceiling fan in one room will help your cooling issues in the rest of the house.

@HU-867564120, this is true, I was just hoping that a minor change here wouldn't make it worse, ya know? Right now the outside temperature is in the high 70s and it feels hotter than that in our offices, even though the thermostat is at 74.

And when it gets to the high 90s the electric bill is insane!

Close down the lower level registers.

Well, that leads me to a different question... since most of the air intake comes from the basement, is it better for the basement to be colder and suck in colder air so that it doesn't have to cool the air as much?

Increase the blower speed.

I don't think that I can, my only options are On, Off, and Auto :-(

Increase the attic insulation.

Definitely not a bad plan! It's pretty thick right now, but considering all of the work I've done on the house over the years I suspect that it's the cheapest insulation they could find. When I have some money, I would love to take it all out and replace it with a higher R insulation.

Install sun blinds.

That got complicated, too... we both have plants in our windows, and we don't really want to trade the plants for temperature.

Move the attic access so your girlfriend can have a ceiling fan.

When I get enough money, that's definitely not a bad plan, either!

In my dream world I would convert the upstairs to have 2 large bedrooms and a walk-in closet instead of 3 small ones, finish the attic to use it for storage or a loft, then install a permanent stairway and door. Right now it has a rickety hatch that's kind of in the way.

But... ya know... money :-(

Lower the thermostat setting.

Last Summer our electric bill hit $400! We were trying to be more conscientious this year, but I'm starting to think we don't have much of a choice :-(

Switch offices so you swelter and your girlfriend has a ceiling fan.

Haha, I promise that I'm not evil!! She chose that room on purpose; mine has 2 windows (one East facing and one South), and her office has one (South facing). She gets up earlier than I do and the sun in the East facing window glares on the computer screen in the mornings.

The basement has a movie theater, game room / bar, gym, and laundry room. I'm half tempted to rip out the gym and game room and change them to 2 offices, then we could just relocate twice a year to where it's the most comfortable. It would take a little money, and it would kinda suck to lose the gym and game room, but it's definitely something that's on the table.
Related Discussions
Brand New Rheem Heat Pump Outside Fan not Blowing
Q
Comments (13)
Short cycling occurs when the AC has much more capacity than the heat load of the house. The AC turns on and cools the house very quickly. Quickly could mean 10 - 20 minutes. The short amount of time does not allow the AC to lower the indoor humidity. You feel cool but your are still sweating. It becomes a problem if you live in an area which has high humidity. The 5 ton capacity refers the size of the condenser. The blower in the air handler is adjusted to work with various condenser sizes. Your handler may be able to work with a smaller condenser. I don't have a good feeling about the installation contractor. He has done a poor installation and appears to be avoiding you. What type of warranty does he provide? Make sure you document the problems and stay on top of him.
...See More
Heat/AC trickles on main level, blows hard downstairs, 1966 house
Q
Comments (7)
Technical writers are woefully under-employed in all fields! We didn't find the manual for the heater, found most of the others that we filed when we moved in here. And finding a schematic on line for our furnace, Armstrong Air Ultra V Advantage 93. Last winter we had to empty some tube that kept filling up with water, a pressure valve I believe, because the heater would stop firing when the water was full. We'd take a cup and pull the plastic hose off, let it drain into the cup and put the clearish plastic hose back on. Now my husband is finding another hose full of water, and it seems to be leading back to our humidifier, an Aprilaire 550. We've never (I know, I'm ashamed to admit it) done anything to service the humidifier or change the filter. This weekend we will spend some time reading up on the proper care and maintenance of the humidifier, including how to change the water panel evaporator (he just came upstairs saying those words--Google help me!) He's looking for some way to identify the circuit damper. There is no error code with the lights, they are blinking "normal." Slow and deliberate. We'll figure this out and learn along the way. In the meantime, we're spot-heating with our little electric woodstove-style fireplace. 'Tis cold in our neck of the woods tonight! If we need it, the heat will work. It just doesn't blow worth anything upstairs and now that we think about past performance, the downstairs vent doesn't blast us anymore when we sit in the chair near it. The heater runs for several minutes, kicks off for a short time, then does it again. Then we're at the temp set on the thermostat and good to go for awhile. Horribly inefficient. This is why our cooling bills were outrageous. I still cannot believe that we didn't figure this out in the summer.
...See More
Ceiling Fan Blowing into the Attic, Okay?
Q
Comments (12)
there has to be a better solution..maybe a bath vent fan ducted out of the attic? the holes cut in ceilings allow attic air/temps and particulate matter to be sucked into the living space when central system is in use. we seem to be cutting lots of holes in ceilings and few properly seal these holes. a lot of heat/cooling loss if from living space to attic. air barriers and insulation need each other to work. the easy fix is the one that cost little, but you pay every month to the utility company. a higher cost, proper install will quickly pay back. but I only know what you've posted. fwiw I keep my house warmer and cooler for my not so young dog. but I have a good air barrier to the attic, well installed insulation. best of luck.
...See More
Split-level house kitchen renovation, Holiday Cabinets
Q
Comments (19)
Thanks so much for the kind words, all! This was my first kitchen remodel and it was not without its challenges! But in the end, it was well worth it... a2Gemini -- the under cabinet lighting is not LED, i think it's xeon. That was a miss IMO -- if we had gone with LED I could have saved my cabinet installer the trouble of hiding the lighting (he had to install all those little strips of wood twice, as the first time they were done incorrectly. If I had to do it over, I would have gone with LED -- flatter, easier and cleaner. By the time I figured this out, though, the tile had been laid, so too late. Badgergal and gsciencechick -- That entry painting is from a local artist, and yes, both the entry hall fan and the light fixture in the dining room are project scope creep! In the six months since these photos were taken, the wood has darkened a wee bit, which is fine by me. AnnaA -- Lovely kitchen! We debated taking down that wall but ours was load bearing and at the end of the day we wanted a bit more separation of living room from kitchen. Yours looks great! The subway tile is not white, it's actually Ann Sacks Savoy Cornflower blue, which is gorgeous in person, you can't see the detail from the photos but each tile is tinged in a blue outline. And for all you 60's split-level lovers... it occurred to me, as I was doing this remodel, that in its day, this house style was considered modern, a big change from the styles that preceded it. And that remodeling our kitchen in flat panel contemporary was actually paying homage to and appropriate for that period. The light over the dining room table is also a nod to 60's design (which I am old enough to have lived through the first time as a child...If only we had kept those danish modern side tables!) I too love seeing the rebirth of these modest-sized homes as they are adapted for our times. -- goldchip
...See More
wwu123
2 years ago
The reason you run it blowing downwards in the summer is that the air moves fastest leaving the blades, so if you're typically near the center of the room, the fast air creates an evaporative effect on your skin, further cooling you off. But it's not changing the temperature of the air, just circulating it in the room. But "circulate" is the key word, the pressure in the room evens out so equal amount of air is moving back up around the greater area of the sides of the room, so more slowly. Conversely in winter you don't want that faster air blowing directly on your skin, so you blow the opposite way, and the room mixes with only slower air coming down the sides of the room and back to center.

My understanding is thus running it in either direction will mix a roughly equal amount of air between the floor and ceiling levels of the room, ignoring the evaporative cooling effect on skin. So to your question, neither direction will bring up air from the basement, you're just mixing the floor and ceiling air in the room itself, as the air is returning in the opposite direction along the walls slowly enough you don't feel it.

Your intent of "pulling" the cooler air upwards from the basement would only work, and probably minimally, is if there was a return air path constructed from the ceiling above the fan straight down into the basement, and some way of forcing the air through that instead of its path of least resistance down the sides of the living room back to the floor.
Jason, zone 7A, near Greensboro NC thanked wwu123
