Adding ground wires to old house wiring.

15 years ago

My old house has two prong outlets that I want to replace with three prong outlets and add a gound wire. Do all the new grounds have to go all the way to the panel ground connector? Can I clamp some of the new ground wires to a #6 or #8 wire in a basement junction box and run the heavier ground wire from there to the panel. Thanks ya'll

Sort by:Oldest

Comments (5)

billhart
15 years ago
They need to have a path back to the panel (don't pretend you found "ground" on a pipe somewhere), but they don't need to be individual wires all the way back. You can join up grounds, and a #12 or #14 is ok.

These are to carry the current from one fault somewhere for the time that it takes to trip the breaker, so they don't need to be bigger than the branch circuit wires and how many you join up doesn't affect wire size needed since we assume only one will be conducting fault current at a time. Connect the ground wires to any junction boxes along the route. You don't need to add additional junction boxes just for the grounds.

The ground should follow as closely as practical the route of the hot and neutral on each circuit. If a fault current has to make a big loop (hot from the panel, fault somewhere to ground, and a different path on the other side of the house back to the panel) the breaker trip time can be extended because magnetic field effects limit the current. You want a very large fault current for a very short time to trip the breaker fast, not 40 amps for a long time heating things up before the breaker trips.
cobraguy
15 years ago
If you currently have individual wires in conduit, you can add an individual ground by pulling it through the conduit. But I don't believe you can just add an individual ground wire without it being in conduit or romex. Feel free to correct me if I'm wrong about this.

You can also protect a circuit with a GFCI and add 3 prong plugs. There will be no equipment ground and you must label the outlets accordingly.
Related Discussions
Quick Check on Adding a Ground wire for a 4-wire Hot Tub
Q
Comments (1)
The main panal in older houses you will put he White (neutral ) and the ground toghether on the same bar. I have seen some new houses that have the white on one side and the ground an the other , but if one was to look carefully they are the same bar and are connected on the bottom. The ground should be the same gauge or bigger than the Hot wires. #6 is good for your Hot tub run. You are correct about the Hot tub end hook ups. The only thing is that the "load side of the gfic does not hook up to the white bar. Only the line side will do that. Since the tub is pre wired this will not be and issue and you will just attach the wires to the connections as shown in the directions. When you power it up you will generally need to reset the gfic trip button as it needs to be powered up for this to happen. enjoy the tub.
...See More
Romex w/o ground wire? Old dryer circuit question
Q
Comments (7)
OK, now I'm even more confused. My parents had an electrician out, and he connected the ground terminal of the receptacle to a nearby water pipe (the washer pipe, on the outside of the wall). As we know, this is not the right way to do it, but this is what the electrician did. There is 240v between the two hots, and 120v between the hots and the ground, so he was satisfied. But the dryer still did not work, so he said they need to have someone come check the dryer. So they called out an appliance person. And he says it's the receptacle, the way it's wired is wrong (neutral to the water pipe). To demonstrate, he manually connected two of the dryer cord prongs (one hot, one ground) to the hot/neutral of a nearby 120v outlet and the motor worked. So, this leads to two questions (just out of curiosity--I know we need to run a new cable). 1. Why does the dryer not work when the neutral is run to the water pipe? 2. How did the thing work before? I still am not sure what the ground terminal was connected to originally, but I can't imagine it was anything other than some plumbing pipe in the wall.
...See More
Adding a ground wire
Q
Comments (6)
Thanks for the fast responses! Unfortunately, the cable feeding the switch is old as well. I considered adding an entirely new circuit to supply my new lights but my main problem is i cannot access the old cables that i would be abondoning. If I abandon the current setup...im assuming i would just have to terminate the cable in the attic in a junction box...not a big deal. But i would also have to put a cover plate over the existing wall switch? Im not thrilled about that idea. And if i ran new romex i could not feed the new cable to a place that is relatively close to the old switch which is important to my wife. Guess, that is why i was hoping to somehow just ground the existing set up.
...See More
Old 3 wire dryer in new house with 4 wire receptacle
Q
Comments (6)
Put the 4 wire receptacle back in just like it was and take the 3 wire receptacle back. Purchase a 4 wire cord for the dryer. The middle terminal on the dryer should have some kind of jumper, either a bare metal strip or a green wire, that gets removed. There should be a place marked where the green wire in the cable goes on the dryer. The black, white and red wires in the cable go to the terminal block. There should be a diagram for all this on the dryer. The standard for dryer wiring is to use 4 wires instead of 3 and it is not code compliant to change back to 3 wire.
...See More
arichard21
15 years ago
I am going to agree with cobra guy on this... ALL of your conductors need to be in the same casing, weather it be conduit or sheathing (romex). The best course of action like corbaguy suggested is to gfi protect.
normel
15 years ago
OK Cobra, I will correct you. You are allowed to run a ground wire separate from the other conductors when grounding an otherwise ungrounded circuit [250.134(B)Exception 1]. However, it is usually just as easy (or difficult) to replace the entire cable with grounded cable.
cobraguy
15 years ago
Thanks Normel. I actually came across one of Brickeyees posts on another thread that said the same thing. My thought process was running THHN through the house and not being in conduit.
